Dock 2

The more capable yet noticeably smaller DJI Dock 2 deploys Matrice 3D or 3TD drones with ease and security. Dock 2 is lightweight, offers high-level operation capabilities, and has cloud-based intelligent functions that bring efficiency and quality to automatic operations.

The all-new DJI Matrice 3D/3TD is specifically designed for DJI Dock 2. Matrice 3D is equipped with both a tele camera and a wide-angle camera with a mechanical shutter, meeting the needs for 1:500 high-precision mapping tasks. Matrice 3TD, outfitted with a wide-angle camera, a tele camera, and an infrared camera, can depict both visible light and thermal images, making it suitable for security and inspection operations.
  • 50-Min Max Flight Time
  • IP55 Rating
  • BVLOS Operation
  • 32 Min Charging Time
  • 6-Directional Sensing & Positioning
  • -13º to 113º F – Operating Temperature
  • Aircraft Dimensions
    335 x 398 x 153 mm
  • Dock Dimensions
    570 x 583 x 465 mm
  • Dock Weight:
    Approx. 34 kg

Coming Soon

Product Highlights

Lightweight and Easy to Deploy
IP55 Ingress Protection
10km Max Effective Operating Radius
Integrated Environmental Monitoring Sytem
Cloud-Based Modeling
FlyTo Tasks
Private Deployment
Third-Party Payload Support

Easy Deployment
Ready to Go

Lightweight Design

DJI Dock 2 is 75% smaller and 68% lighter than its predecessor and is easily transportable with just two individuals, which makes for flexible installation and reduces installation costs.

Efficient Site Evaluation

Before deployment, the aircraft can detect the surrounding environment using vision sensors and quickly determine whether the area has strong GNSS signals. This new vision-based evaluation markedly accelerates site selection, reducing the required time from five hours to twelve minutes or less.

High-Performance Aircraft Models

The DJI Matrice 3D/3TD is specifically designed for DJI Dock 2. Matrice 3D is equipped with both a tele camera and a wide-angle camera with a mechanical shutter, meeting the needs for 1:500 high-precision mapping tasks. Matrice 3TD, outfitted with a wide-angle camera, a tele camera, and an infrared camera, can depict both visible light and thermal images, making it suitable for security and inspection operations.

Matrice 3D

Wide-Angle Camera

      • 4/3 CMOS
      • 24mm Format Equivalent
      • 20MP Effective Pixels
      • Mechanical Shutter

Tele Camera

      • 1/2-inch CMOS
      • 162mm Format Equivalent
      • 12MP Effective Pixels
Matrice 3TD

Wide-Angle Camera

      • 1/1.32-inch CMOS
      • 24mm Format Equivalent
      • 48MP Effective Pixels

Tele Camera

      • 1/2-inch CMOS
      • 162mm Format Equivalent
      • 12MP Effective Pixels

Infrared Camera

      • 40mm Format Equivalent
      • Normal Mode: 640X512 @ 30fps
      • UHR Infrared Image Mode: 1280X1024 @30fps
      • 28X Digital Zoom

APPLICATION SCENARIOS

Discover the evolution of industrial operations with drones. Learn about their practical applications within your specific industry.

Inspections

Drone-powered routine inspections and safety monitoring improve efficiency without halting operations or compromising personnel safety.

Public Safety

Respond effectively with aerial insights. Collect important data in real time. Direct aid where it’s needed most.

Survey & Mapping

Discover how drones are reshaping the survey and mapping industries, offering unparalleled efficiency, safety, and accuracy in data collection.
