Live Deck 2

SKU102001438

Watch a livestream of what your drone sees on a variety of display types with the Live Deck 2 Video Transmitter for EVO II V3 Drones from Autel Robotics.

Related Products

Description

Watch a livestream of what your drone sees on a variety of display types with the Live Deck 2 Video Transmitter for EVO II V3 Drones from Autel Robotics. Other team members can assist pilots in achieving the best shot or accomplishing the mission more easily by viewing a livestream from an EVO II V3 drone. The Live Deck 2 can output Full HD video at 60 fps to a TV, PC, or up to four smartphones via its HDMI, Ethernet, and USB-A ports, or Live Deck-generated Wi-Fi. Autel equipped the Live Deck 2 with dual antennas for a 7.5-mile range and a host of features to ensure a stable and clear image.

Additional Information

Specs

Weight: 424.5g
Dimensions:
152*111*23.2mm (antennas folded)
223.9*152*23.3mm (antennas unfolded)"
Ingress Protection: IP43
Operating Frequency:
902-928MHz（FCC）
2.400-2.4835GHz
5.725-5.850GHz（Non-Japan）
5.650-5.755GHz（Japan Only)
Transmitter Power (EIRP)：
900MHz: FCC<=33dBm
2.4GHz: CC/NCC<=33dBm; CE/MIC/SRRC/KC<=20dBm
5.8GHz/5.7GHz: FCC/SRRC/NCC<=33dBm; KC<=20dBm; CE<=14dBm"
Max Transmission Distance (unobstructed, free of interference)： 12km
Operating time： 5h
Operating Current/Voltage： 1.3A/3.85V (not connected to smartphone)
Battery Type： Li-Po
Battery Capacity： 6200mAh
Rated Power： 5 W
Operating Temperature：14°F~104°F (-10°C~40°C)
Operating Humidity： 95%RH
HDMI： 1080p@60 fps
Ethernet： 100M
